Adobe Creative Suite applications like Adobe InDesign and Adobe Illustrator support many kinds of transparency. You can assign opacity and blending mode attributes to objects. You can create effects like drop shadows and glows. And you can place graphics from other applications in the PSD, TIFF, AI, and PDF formats (PDF files must be Acrobat 5.0 compatibility or higher) which contain transparency.

For example, in the example from Adobe Illustrator below, there are two circles stacked on top of each other. The top one is selected. The Transparency panel shows that it has an opacity setting of 50% so it is considered transparent. This transparency is considered live transparency because it’s still editable.

Many commercial printers use PostScript RIPs that require the flattening of transparency. The PostScript language they use was written before transparency was supported in artwork. When artwork is flattened objects must be broken into pieces (“atomic regions”) but flattening process attempts to maintain the appearance of the original

In the example below, the objects have been flattened. They are no longer editable, and all of the objects are opaque. (The objects are moved apart to show the pieces of the original.)

Flattening can happen by printing to a PostScript file, or when you export to a PDF file and choose a PDF preset that supports flattening transparency—for example, PDF/X-1a or PDF/X-3. We discussed selecting a PDF preset in another blog post.

Need help with your print? Talk to a live print expert today: 800-930-7978.

In my previous two blog posts, I talked about the usefulness of saving PDF files in Photoshop and Illustrator, and how you could choose the best PDF presets.

While the default settings are good for many purposes, there are times when you might want to customize them. I can’t go into all the reasons you might want to do that, but I’ll give you an example.

I mentioned last time that the High Quality Print PDF preset, found in both Photoshop and Illustrator, is good for high-quality printing on desktop printers and proofers.

However, the default resolution is set very high—300 ppi for both color and grayscale images. Many desktop printers don’t require that much resolution, and, if you have a larger image or document, you might want to set that lower.

The way you customize a PDF presets differs somewhat between Photoshop and Illustrator. Here’s the Adobe Illustrator method:





.







Start with the PDF preset you want to modify. Choose the settings you want to change. Here I reduced the downsampling on the Compression panel to 150 ppi for color and grayscale images. Click the button to the right of the preset. Then name your new preset.

Here’s the Photoshop method:















Start with the PDF preset you want to modify. Choose the settings you want to change. Here I reduced the downsampling on the Compression panel to 150 ppi. Click the Save Preset button to the bottom left of the dialog. Then name your new preset.

Need help with your print? Talk to a live print expert today: 800-930-7978.

I remember the first time I encountered the term CMYK. I was just a kid, probably 15 or 16 years old, and I was working on my family’s Mac.

At the time I didn’t know a thing about the printing industry, but I was fooling around with the color settings in MacPaint and saw three options: Grayscale, RGB, and CMYK. I switched between the three to see what would happen (which, of course, was nothing, because the tiny screen was black and white anyway).

But RGB made sense, conceptually: red, green, blue. Nothing scary about that.

But CMYK? CMYK was mysterious and strange, and therefore should be feared at all costs. I switched the color settings to anything but that.

CMYK Makes the Print World Go ‘Round

As it turns out, I had CMYK all wrong. CMYK (which stands for cyan, magenta, yellow, and black) is nothing to be afraid of. It’s just another color system, like RGB.

But if you’re a print buyer, designer, or jack-of-all-trades small business owner, it’s important to know what those color settings mean when it comes time to create printed content.

I won’t explain the physics behind RGB and CMYK here, but if you’re interested, find more information here on the three different color systems for printing (including Pantone), the science behind the CMYK color model, and how the RGB color model works.

RGB vs. CMYK

The RGB color space is huge, as it incorporates all of the visible spectrum of light. A range of colors (literally millions) are available to choose from in RGB, and electronic display devices like computer monitors and televisions use that spectrum.

CMYK is a much smaller color gamut offering thousands of colors. It’s the color system used for offset lithography, the main printing process you’ll find being used at commercial printers.

Here are the main differences between RGB and CMYK, as they pertain to printing:

RGB vs. CMYK
	RGB	CMYK
Type of color mixing	Additive	Subtractive
Number of colors	Millions	Thousands
Main use	Digital display	Print materials
Conversion	Doesn’t always convert to CMYK	Converts easily to RGB

Why Converting RGB to CMYK Can Be Tricky

Think of the RGB color space as a large circle of options, with the CMYK color space taking up a smaller circle within it.

In other words, while you can recreate just about any CMYK color on a screen, it doesn’t go so easily the other way around.

All pieces designed in the RGB color space must go through a RGB to CMYK conversion process to be printed on a press. A little preparation upfront is well worth it later — after all, it’s obvious that if you choose a color in RGB that doesn’t exist in CMYK, there might be a big problem when it comes time to get your file ready for the press.

The CMYK Blue-Purple Conundrum

One of the most common problems I see when converting RGB to CMYK are with blues and purples. Often, strong blues (think neon blue, or navy blue) turn purple when printed as CMYK.

Here’s why: the software or device that’s converting the color, whether it’s Adobe Photoshop, Adobe Illustrator or even Microsoft Publisher, is trying to come up with a solution for a color that doesn’t exist — so it comes up with something it thinks is close.

If this sounds like you, you’ll need to select a CMYK or Pantone color that most closely matches your brand rather than trying to convert from RGB to CMYK.

Fixing RGB to CMYK Issues with a CMYK Color Chart

Enough with the problems, how do we solve this thing?

If you have a digital design that you’re nearly ready to print, most programs allow you to switch to CMYK mode to help insure against unpleasant surprises when your design hits the printing process. You can also use an online RGB to CMYK color chart to switch between the two systems.

This is the DIY method, though, and there are a few pitfalls to it:

• Paper stock. What matches your brand exactly in CMYK may look completely different on the final type of paper your printer uses for your project.
• Branded elements designed in RGB. If your logo or brand colors were originally designed in RGB, they may not actually exist in CMYK — requiring a rebrand or a lot of headaches trying to work out how to translate your digital content into print.
• Inexperienced designers. As a rule of thumb, check with a designer to see if they have print design experience before hiring them for a job. If you pick an inexperienced designer, the quality of your content will suffer.

If you’d rather eliminate the guesswork, the best plan is to have a good consultative relationship with your printer. Your printer can provide you with a CMYK swatch book printed on the paper you’re going to use for your project so you can make sure your colors look superb before you spend a penny on printing.

A little research upfront can provide you a massive return on investment, plus the peace of mind that you’re creating fantastic looking print materials to represent you and your brand. Don’t hesitate to reach out to Printing for Less for advice at [phone number] or [email address] — we’ve been doing this print thing for over two decades (and I’ve come a long way since my days of CMYK terror!)
